C-Silver Indoor cabinet all-in-one ESS compatible with three phase 8kw/10KW/12KW hybrid solar inverter, BYD 180AH-300AH vehicle grade LiFePO4 battery and battery management system(BMS) for residential energy storage system application .
Category：Residential Energy Storage Systems, battery storage inverter, solar systems, inverter solar, energy storage system
● Low-voltage LiFePO4 battery module, single module is 25.6V 200/300AH;
● Easy installation.
●BYD vehicle grade battery cell (LFP), more safety, longer life cycle, more usable energy;
●System cycle life ≥ 6000 times;
●Support peak load shifting and important load backup;
●Integrated BMS management system to support intelligent management;
●Compatible with CANbus/RS485 communication interface;
●It is more economical to support multiple operating modes;
| Model | SNE51.2FL200 | SNE51.2FL300 |
| Performance | ||
| Battery type | Lithium-iron phosphate (LiFePO4) | |
| Nominal battery energy(KWH) | 10.24kWH | 15.36kWH |
| Nominal capacity(AH) | 200AH | 300AH |
| Nominal voltage(V) | 51.2V | 51.2V |
| Operating voltage Range(V) | 43.2-57.6V | 43.2-57.6V |
| Number of battery Modules | 2 | 2 |
| Rated charging current(A) | 66A | 99A |
| MAX. constant charging current(A) | 100A(@25℃) | 150A(@25℃) |
| Rated discharge current(A) | 66A | 99A |
| Max.constant discharging current(A) | 200A(@25℃) | 300A(@25℃) |
| Depth of discharge(DOD) | 80% | |
| Cell technology | BYD lithium-iron phosphate (LiFePO4) | |
| Design life | ＞6000 times @80%DOD | |
| Warranty | 5 years | |
| Warranty document supplied | Yes | |
| Compatible hybrid inverters | Low voltage hybrid inverters | |
| Protection function | ||
| Protection | Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function | |
| Communication | ||
| Communication | CAN/RS485 | |
| General Specification | ||
| Dimension (L*W*H)(MM) | 730*1000*185 | 730*1000*185 |
| Weight(KG) | 150KG | 150KG |
| Shipping status SOC | 20%~30% | |
| Charging temperature | 0 – +50°C | |
| Discharging temperature | -20~+55℃ | |
| Short term storage ambient temperature | -10-+45℃(<3 months,S0C: 20%-60% SOC) | |
| Long term storage ambient temperature | -10+35℃(<1 month,S0C: 30%-60% SOC) | |
| Max. operating altitude | 4,000m(Derating above 2,000m) | |
| Protection degree | IP21, indoor installation | |
| Relative humidity | 5%-95% | |
| Cooling | Natural convection | |
| Noise emission | <29 dB | |
