SNE-ESS105KR215C outdoor all-in-one ESS solution compatible with lithium battery storage, which used BYD LiFePO4 battery module and original BYD high voltage control box, comes with SNE 105KW hybrid solar inverter.
Easy to install and dispatch, with built-in HVAC/FSS (optional), and could be used in parallel. It is a compact and flexible ESS designed by C-silver based on the characteristics of small C&I loads.
The system integrates core parts such as the battery storage system, PCS，DCDC, STS, fire extinguishing system, temperature control systems, and EMS systems in one cabinet. The clean solar energy is the best choice for small-scale industrial and commercial use and electricity store, and saves high electricity bills.
Category：C&I Energy Storage System, electricity store, BYD blade cell, LFP battery, outdoor cabinet, inverter solar, solar systems
●Integrate PV, PCS, STS, EMS and LiFePO4 Battery in one cabinet;
●Wide PV input voltage range, wide battery voltage range;
●Simple structure, small footprint, flexible layout, easy installation operation and maintenance;
●Use of high performance DSP, optimized control circuit design, better performance, more stable and safe system;
●Modular design, power and capacity can be expanded;
●Communication is flexible, can accept BMS instructions in real time, communication methods are RS485, CAN;
●The highest efficient power density, max. efficiency is 98.5%;
●Low power consumption fan, with intelligent temperature control system;
●With grid-connected charging and discharging, off-grid independent inverter function;
| Model | SNE-ESS105KR215C |
| PV Input | |
| Max. Power(KW) | 50KW*2 |
| Max. DC Voltage(V) | 1000V |
| MPPT Voltage Range(V) | 300V-1000V (450V-850V Full Load) |
| MPPT Tracker/Strings | 2/1 |
| Max.Input Current of Single MPPT(A) | 80A |
| Battery Input | |
| Battery Type | Lithium Iron Phosphate(LiFePO4) |
| Battery Module | 51.2V 280AH BYD Battery Module |
| Battery Capacity(KWH) | 215KWH |
| Nominal Voltage(V) | 768V |
| Battery Voltage Range(V) | 648V-912V |
| Number of Battery Clusters | 1 |
| Standard Charge/Discharge Current (A) | 92.4A |
| Max. Charge Current (A) | 140A |
| Max. Discharge Current (A) | 280A |
| AC Output | |
| Rated Output Power(KW) | 105KW |
| Max. Apparent Power(KVA) | 116KVA |
| Max. Current(A) | 167A |
| Grid voltage/range(V) | 230V/400V, 230/400, (3W+PE) 3 P3W/(3W+N+PE)3 P4W |
| Frequency (Hz) | 50/60Hz |
| PF | 1 Lagging-1 Leading |
| THDI | ＜3%（Rated Power） |
| EPS Output | |
| Rated Output Power(KW) | 105KW |
| Max. Apparent Power(KVA) | 116KVA |
| Max. Output Current(A) | 167A |
| Rated Output Voltage(V) | 230V/400V |
| Rated Frequency (Hz) | 50/60HZ |
| THDU | <3% (Linear Load) |
| Overload Capacity（AC） | 110%，Long-term |
| Protection | |
| Anti-island Protection | Yes |
| DC Reverse Connection Protection | Yes |
| DC Surge Protection | Yes |
| AC Surge Protection | Yes |
| AC Overcurrent Protection | Yes |
| AC Short-circuit Protection | Yes |
| AC Overvoltage Protection | Yes |
| General Data | |
| Euro Efficiency | 97% |
| Max. Efficiency | 98.50% |
| Relative Humidity | 5 ~95% （Non-condensing） |
| Altitude | 5000m (>3000m derated) |
| Dimensions (D/W/H) mm | 1550*1900*2020MM |
| Weight(KG) | About 2860KG |
| Inverter Topology | Transformerless |
| Ingress Protection | IP54 |
| Fire Extinguishing System | Support |
| Operating Temperature | -30℃~55℃ |
| PCS Cooling Way | Intelligent Fan |
| Battery Cooling Way | Air Conditioning Cooling |
| Display and Communication | |
| Display | 7 Inch Touch Screen |
| Battery Communication | CAN/RS485 |
| Standards | |
| Inverter Grid Regulation | EN IEC 61000-6-2:2019/2016, EN IEC 62109-6-4:2019/2018, NRS097, G99,EN50549 |
| Battery Standards | UN38.3/MSDS/IEC62619/CE |
| Standards | |
| Inverter Grid Regulation | EN IEC 61000-6-2:2019/2016, EN IEC 62109-6-4:2019/2018, NRS097, G99,EN50549 |
| Battery Standards | UN38.3/MSDS/IEC62619/CE |
